So I've figured out my space limitation/controller mounting issues after going over dozens of scenarios.
In the end, it was simple, it's the LED psu/drivers that were the bulkiest and pushing everything else out, either the sump outward which cascaded onto moving everything else.
So, I changed the led box. Instead of one big box, I split the driver board and PSU, made both a lot slimmer, and allowed one to be mounted up top, and one on the back wall.
Old on top, new ones below.
Current state of the cabinet:
I also quickly put together the small fuge light with the leftover led strip. I didn't like the look of the printed white on the outside, so I also printed a thin black cover that slips onto this one.
